RBT uIBX-210-CV-N2600

»Slim and compact embedded system design with 3rd Gen Intel® Atom™
N2600 dual-core processor, supports DDR3 memory (system max: 2 GB)

»12V only single voltage design, supports AT/ATX power mode selection

»Flexible VGA and HDMI with dual-display support

»Supports PCIe Mini card slot

»Fully I/O with four USB, one VGA, one HDMI, three COM and audio

Category: Pc

Description

SPEC ITEM	DESCRIPTION
Color
Color	Silver
Dimensions
Dimensions	146.6 x 132 x 45.2
Environment
Humidity	5% ~ 95%, non-condensing
Operating Temperature	0°C ~50°C with air flow (mSATA)
Expansion Slots
Expansion Slots	PCIe Mini 1 x Full size (reserved for Wi-Fi module)
Form factor
SBC Form Factor	CPU:Intel® Atom™ N2600 1.6 GHz Chipset:Intel® NM10 System Memory:1 x 204-pin DDR3 SO-DIMM (system max: 2 GB) Pre-installed 2 GB
I/O Interface
I/O Ports	4 x USB 2.0 Ethernet: 1 x RJ-45 1 x PCIe GbE by Realtek 8111E RS-232:2 x DB-9 RS-422/485:1 x RJ-45 Display:1 x VGA, 1 x HDMI Resolution: VGA: Up to 1920 x 1200 HDMI: Up to 1920 x 1080 Audio:1 x Line-out, 1 x Mic-in Wireles:1 x 802.11b/g/n (optional)
System
Cooling method / System Fan	Fanless
Drive Bays	1 x 2.5’’ SATA HDD bay
Weight
Weight	980 g/1.8 kg
