Description
| SPEC ITEM | DESCRIPTION |
|---|---|
| Color | |
| Color | Black |
| Dimensions | |
| Dimensions | 290 x 75 x 225 |
| Environment | |
| Humidity | 5% ~ 95%, non-condensing |
| Operating Temperature | -15°C ~ 55°C with air flow |
| Expansion Slots | |
| Expansion Slots | 2 x Full size |
| Form factor | |
| SBC Form Factor | CPU: Intel® mobile Core™ i5-4400E (2.7 GHz, 37W) Chipset: Intel® QM87 System Memory: 2 x 204-pin DDR3 SO-DIMM slot (system max. 16 GB) Pre-installed 4 GB DDR3 SO-DIMM |
| I/O Interface | |
| I/O Ports | 1 x PS2 (KB/MS) 2 x USB3.0 2 x USB2.0 2 x RJ-45 with teaming support 1 x PCIe GbE by Intel® I217LM 1 x PCIe GbE by Intel® I210-AT (2 with 2 kV isolation) 1 x DB-9 (non-isolated) 4 x RS-232/422/485 (with 2.5 kV isolation) 2 x CAN-bus (with 2.5 kV isolation) 1 x VGA 1 x DVI-D 1 x HDMI 1 x Line-out, 1 x Line-in, 1 x Mic-in 2 x Antenna SMA hole (reserved) |
| Indicator&Buttons | |
| Indicators | Power (power on: green, power off: orange), storage (red, blinking), IPMI (blue) |
| System | |
| Cooling method / System Fan | Fanless |
| Drive Bays | 2 x 2.5” SATA 6Gb/s SSD bay with RAID 0/1 function |
| Weight | |
| Weight | 4.08 kg / 6.03 kg |
