Description
| SPEC ITEM | DESCRIPTION |
| System | |
| Processor | 7th/6th Generation Intel® Core™ i7/i5/i3/Pentium®/ Celeron® 14nm LGA1151 Socket Processor |
| Chipset | Intel® H110 |
| Memory | 288-pin DIMM x 2, max. 32GB, DDR4 2400/2133/1867, Dual channel |
| I/O Chipset | NCT6791D, F81216HD |
| Ethernet | Intel® I211AT Giga LAN x 2 |
| Audio | Realtek® ALC887 (Colay with ALC886) |
| TPM | Nuvoton NPCT650ABBYX TPM2.0 (default : No) |
| Expansion Slot | PCIe [x16] x 1, PCIe [x1] (open edge) x 2, PCI x 1, M.2 M key (22 x 42mm) x 1 |
| BIOS | 128M bit Flash ROM x 1, AMI BIOS |
| H/W Monitor | Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/3.3V/12V/ 3VSB/VBAT, Fan Monitor on CPU/Chassis |
| Watchdog Timer | 1~255 steps by software program |
| Smart Fan Control | CPU Fan x 1, Chassis Fan x 2 |
| Wake On LAN/ PXE | Yes (WOL/PXE) |
| Power State | S3, S4, S5 |
| Graphics | |
| Graphics Chipset | Intel® HD Graphics |
| Graphics Multi Display | DVI-D+HDMI, HDMI+HDMI, VGA+HDMI, DVI-D+VGA |
| VGA | Up to 1920 x 1200 @60Hz |
| DVI | Up to 1920 x 1200 @60Hz |
| HDMI | HDMI 1.4 up to 4096 x 2304 @24Hz |
| DisplayPort | — |
| LVDS | — |
| eDP | — |
| Backlight Control | — |
| Environmental & power | |
| Battery | Lithium battery |
| Power Requirement | 24-pin ATX connector x 1, 8-pin ATX 12V Power connector x 1 |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% RH, non-condensing |
| Certification | CE & FCC Class A |
| Form Factor | Micro-ATX, 9.6” x 9.6” (244mm x 244mm) |
| Weight | 1.76 lb (0.8 Kg) |
| MTBF (hours) | 245,250 |
| Rear panel I/O ports | |
| USB | USB 3.0 x 4 |
| Display I/O | HDMI x 2, VGA x 1, DVI-D x 1 |
| Audio I/O | Line-in, Mic-in, Line-out |
| LAN I/O | RJ-45 x 2 |
| Serial Port | DB-9 COM x 1 (supports RS-232/422/485) |
| PS/2 Port | Stack Port (Keyboard & Mouse) x 1 |
| Others | — |
| Internal I/O connectors | |
| Storage | SATA 6.0Gb/s x 5, M.2 M key (22 x 42mm) x 1 |
| USB | USB 2.0 x 6 |
| Display I/O | — |
| Audio I/O | AMP speaker header x 1 (Line-out) |
| Serial Port | RS-232 header x 5 |
| PS/2 Port | — |
| Parallel Port | — |
| DIO | 8-bit x 1 (In/Out programmable) |
| Fan | 4-pin CPU Fan x 1, 4-pin Chassis Fan x 2 |
| Others | Front panel header x 1, Clear CMOS jumper x 1, BIOS flash header (2[x4]P p=1.27mm) x 1, Chassis Intrusion x 1, AT/ATX mode select jumper x 1 |
| OS | |
| OS support | Windows® 7 32/64-bit (not supported when a Kaby Lake processor is used) |
| Windows® 8.1 64-bit (not supported when a Kaby Lake processor is used) | |
| Windows® 10 64-bit | |
| Linux Fedora 64bit | |
