»AMD G-series T16R Single Core 615 MHz Processor
»AMD A55E
»DDR3L SODIMM 1066 MHz Memory, Max. 4 GB
»Gigabit Ethernet x 2
»VGA, 18/24-bit Dual-channel LVDS LCD
»2CH HD Audio
»SATA 3.0 Gb/s x 1 & CompactFlash™ x 1
»PC/104 Interface Support
»Supports 8-bit Digital I/O, USB2.0 x 4, COM x 4, LPT x 1
»Mini-Card Slot x 1
»+5V Input, AT/ATX
| SPEC ITEM | DESCRIPTION |
| System | |
| Form Factor | 3.5″ SubCompact Board |
| CPU | AMD G-Series T16R/T40R/T56N |
| CPU Frequency | 615MHz up to dual core 1G |
| Chipset | AMD A55E |
| Memory Type | DDR3L 1066MHz, SODIMM x 1 |
| Max. Memory Capacity | 4 GB |
| BIOS | SPI type |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Levels |
| Power Requirement | +5V |
| Power Supply Type | AT/ ATX |
| Power Consumption (Typical) | AMD G-T16R, DDR3 1333MHz 4GB, 2.20A@+5V |
| Dimension (L x W) | 5.75″ x 4″ (146mm x 101.6mm) |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 176°F (-40°C ~ 80°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 148,000 |
| Certification | CE/FCC |
| Display | |
| VGA/LCD Controller | AMD Radeon HD 6250 |
| Video Output | CRT, LVDS, TTL LCD |
| Backlight inverter supply | Up to 24-bit dual-channel LVDS |
| I/O | |
| Ethernet | Realtek RTL-8111E, 10/100/1000Base-TX x2 |
| Audio | High Definition Audio Interface |
| USB Port | USB2.0 x 4 |
| Serial Port | RS-232 x 2, RS-232/422/485 x 2 |
| Parallel Port | SPP/ECP/EPP X 1 (Sharded with DIO) |
| HDD Interface | SATA2.0 x 1 |
| FDD Interface | — |
| SSD | CompactFlash™ |
| Expansion Slot | Mini-Card x 1, PC/104 |
| DIO | 8-bit |
| SIM | x 1 |
| TPM | — |
| Touch | x 1 |
| Touch | — |
| TPM | TPM2.0 x 1 (optional) |
| Touch | x 1 |
