»Intel Core i7/i5/i3/Pentium/celeronLGA1155/1150/775-Socket Motherboard,
»Resistive 5 Wire Touch Screen,
»IP64/65/66Grade Front Bezel,
»I/O:DVI/VGA/2*LAN/5*USB/4*COM/AUDIO/PCIex4/Wifi
| SPEC ITEM | DESCRIPTION |
| Panel | |
| LCD Size | 17″, 4:3 |
| Resolution | SXGA 1280 x 1024 |
| Luminance | 350cd/m2 |
| LCD Color | 16.7mm |
| Viewing angle | 60 (U), 80 (D), 80 (L), 80 (R) |
| Backlight | LED |
| Contrast ratio | 800 |
| System | |
| CPU | on-board Intel® Celeron® Quad Core processor J1900 processor |
| up to 2.42GHz, 2M L2 cache | |
| BIOS | AMI BIOS |
| System memory | 2 x 204-pin DDR3L SO-DIMM socket, 4GB DDR3L |
| (default), support up to 8GB DDR3L-1066/1333, non-ECC and un buffered | |
| Storage device | 1 x External locked CFast socket |
| — 1 x Hard drive bay: optional 1 x 2.5″ SATA HDD or 1 x SATA DOM | |
| Watchdog timer | Watchdog timeout can be programmable bysoftware from 1 second to 255 seconds and from 1 minute to 255 minutes (tolerance 15% under room temperature 25°C) |
| H/W status monitor | monitoring system temperature, and voltage |
| Expansion | 2 x mini-PCIe sockets (support optional Wi-Fi, 3.5G module) |
| Rear I/O | |
| Ethernet | 2 x RJ45 |
| 2nd display VGA port | 1 x DB15 |
| Audio port | 1 x Line-out |
| USB | 2 x USB 2.0, 1 x USB 3.0 |
| Power switch | |
| Reset button | |
| 2-Pin remote power on/off switch | |
| COM #1: RS232/422/485 w/2.5kv isolated | |
| COM #2: RS232/422/485 w/2.5kv isolated | |
| Touch screen | |
| 5 -wire resistive | (flush panel type) |
| Touch light transmission: | 81% |
| Touch interface: | USB |
| Audio | |
| HD audio codec | realtek ALC886-GR |
| Audio interface | Line-out |
| Ethernet | |
| LAN chip | dual Intel® I210AT Gigabit LAN |
| Ethernet interface | 10/100/1000 Base-Tx Ethernet compatible |
RBT 1940T
