Description
| SPEC ITEM | DESCRIPTION |
| Processor | Fanless Intel® Celeron N3160 SoC, 1.60GHz – 2.24GHz Burst, Quad-Core, 6W TDP/4W SDP, with AES-NI support |
| Memory | 2 x 204-pin SODIMM DDR3L-1600 Dual Channel 1.35V required (up to 8 GB) |
| * 1600MHz memory will run at 1600MHz | |
| * 1333MHz memory will run at 1066MHz | |
| * 1066MHz memory not supported | |
| Graphics | Intel HD Graphics 400, 320MHz – 640MHz |
| Audio | Realtek ALC662VD HD Audio |
| LAN | 2 x Realtek RTL8111H PCI-E Gigabit LAN |
| Storage | 1 x SATA3 6Gb/s Connectors |
| 1 x M.2 SATA (M-key, 2242/2260) | |
| Super IO | FINTEK F81866A |
| TPM | Intel fTPM 2.0 (PTT) Trusted Computing Firmware |
| Option: Onboard TPM v1.2 or v2.0 |
