| Panel Brand | KOE | Panel Model | LMG7550XUFC |
|---|
| Panel Size | 10.4 inch | Panel Type | FSTN-LCD , LCM |
|---|
| Resolution | 640×480 , VGA | Pixel Format | Rectangle |
|---|
| Display Area | 211.17(W)×158.37(H) mm | Bezel Opening | 220.2(W)×165.77(H) mm |
|---|
| Outline Size | 264(W)×183(H) ×9(D) mm | Surface | Antiglare, Hard coating (3H) |
|---|
| Brightness | 100 cd/m² (Typ.) | Contrast Ratio | 18:1 (Typ.) (TM) |
|---|
| Viewing Angle | 40 (Typ.)(CR≥2, Φ2-Φ1)  | Display Mode | STN, Black/White (Negative), Transmissive |
|---|
| Best View on | 12 o’clock | Response Time | 160/110 (Typ.)(Tr/Td) |
|---|
| Display Colors | Monochrome | Lamp Type | 1 pcs CCFL , Without Driver |
|---|
| Frequency | – | Touch Screen | Without |
|---|
| Panel Weight | – | Application |  |
|---|
| Signal Interface | Parallel Data (4-bit) , 15 pins , Connector |
|---|
| Environment | Operating Temp.: 0 ~ 45 °C ; Storage Temp.: -25 ~ 60 °C |
|---|
